POWDER COATING CERAKOTE OVENS

4'x5'x7' Powder Coating / Cerakote Oven

Digital Temp Control, Circulation Fan
Unit Price: $3000.00

Also available in custom sizes

4x5x7
ITEMS INCLUDED:

 - Powder Curing Oven

 - User Manual

 - Wiring Diagram

DIMENSIONS:

 - External: 48” x 60” x 84”

 - Internal: 41” x 54” x 80”

DESCRIPTION:

 - Four (4) long-life mineral insulated metal sheathed heating elements

 - The chamber door opens out providing access to the full width of the chamber

 - Chamber walls and door encased with mineral fiber insulation (rated @ 2100F), providing maximum thermal efficiency

 - High temperature silicone compound gasket provides a seal within the curing chamber

 - Double Wall Galvanized Steel (prevents rust and corrosion allowing the unit to last the long term)

 - Sturdy Galvanized Steel flooring, heavy enough to protect the flooring underneath, still allowing users to enter and exit with ease (no reaching deep inside, allowing the use of a cart or fixture to roll in and out of the oven)

 - Industrial Grade Insulation rated @ 2100F

 - Industrial Grade Ball Bearing Hinges

 - Industrial Strength Door Latch

 - High Temperature Gaskets

 - High Temperature Circulation Fan

CONTROL SYSTEM:

 - Side mounted control panel

 - Simple to use digital temperature control, display set temperature as well as actual temperature inside the oven

 - Thermocouple

 - On/Off Breaker Switch

 - On/Off Circulation Fan Switch

4'x5'x6' Powder Coating / Cerakote Oven

Circulation Fan
Unit Price: $4000.00

Also available in custom sizes

4x5x6
ITEMS INCLUDED:

 - Powder Curing Oven

 - User Manual

 - Wiring Diagram

DIMENSIONS:

 - External: 48” x 60” x 72”

 - Internal: 41” x 54” x 68”

DESCRIPTION:

 - Four (4) long-life mineral insulated metal sheathed heating elements

 - The chamber door opens out providing access to the full width of the chamber

 - Chamber walls and door encased with mineral fiber insulation (rated @ 2100F), providing maximum thermal efficiency

 - High temperature silicone compound gasket provides a seal within the curing chamber

 - Double Wall Galvanized Steel (prevents rust and corrosion allowing the unit to last the long term)

 - Sturdy Galvanized Steel flooring, heavy enough to protect the flooring underneath, still allowing users to enter and exit with ease (no reaching deep inside, allowing the use of a cart or fixture to roll in and out of the oven)

 - Industrial Grade Insulation rated @ 2100F

 - Industrial Grade Ball Bearing Hinges

 - Industrial Strength Door Latch

 - High Temperature Gaskets

 - High Temperature Circulation Fan

CONTROL SYSTEM:

 - Side mounted control panel

 - Simple to use digital temperature control, display set temperature as well as actual temperature inside the oven

 - Thermocouple

 - On/Off Breaker Switch

 - On/Off Circulation Fan Switch

4'x4'x6' Powder Coating / Cerakote Oven

Circulation Fan
Unit Price: $3,500.00

Also available in custom sizes

4x4x6
ITEMS INCLUDED:

 - Powder Curing Oven

 - User Manual

 - Wiring Diagram

DIMENSIONS:

 - External: 48” x 48” x 72”

 - Internal: 41” x 41” x 68”

DESCRIPTION:

 - Double walled with galvanized steel sheeting both inside and out



 - Heavy duty galvanized steel flooring, heavy enough to protect the flooring underneath, thin enough to roll carts in and out of the oven



 - Two (2) long-life mineral insulated metal sheathed heating elements

 - The chamber door opens out providing access to the full width of the chamber

- Chamber walls and door encased with mineral fiber insulation (rated @ 2100F), providing maximum thermal efficiency

 - High temperature silicone compound gasket provides a seal within the chamber

 - Ceramic fiberglass door gasket



 - Commercial Grade ball bearing oven door hinges

 - Industrial Strength door latch clamps



 - Made in USA

CONTROL SYSTEM:

 - Side Mounted Control Panel

 - Digital temperature control, display set temperature as well as actual temperature inside the heating chamber



 - Thermocouple
- On/Off Breaker Switch

36'x36'x60' Powder Coating / Cerakote Oven

Digital Temp Control
Unit Price: $2,473.00

Also available in custom sizes

36x36x60
ITEMS INCLUDED:

 - Powder Curing Oven

 - User Manual

 - Wiring Diagram

DIMENSIONS:

- External: 36” x 36” x 60”



 - Internal: 31” x 31” x 57”

DESCRIPTION:

- Double walled with galvanized steel sheeting both inside and out



 - Heavy duty galvanized steel flooring, heavy enough to protect the flooring underneath, thin enough to roll carts in and out of the oven



 - Two (2) long-life mineral insulated metal sheathed heating elements





 - The chamber door opens out providing access to the full width of the chamber





- Chamber walls and door encased with mineral fiber insulation (rated @ 2100F), providing maximum thermal efficiency





 - High temperature silicone compound gasket provides a seal within the chamber





 - Ceramic fiberglass door gasket



 - Commercial Grade ball bearing oven door hinges





 - Industrial Strength door latch clamps



 - Made in USA

CONTROL SYSTEM:

 - Side Mounted Control Panel

 - Digital temperature control, display set temperature as well as actual temperature inside the heating chamber



 - Thermocouple
- On/Off Breaker Switch

24'x24'x48' Powder Coating / Cerakote Oven

Digital Temp Control
Unit Price: $1,100.00

Also available in custom sizes

24x24x48
ITEMS INCLUDED:

 - Powder Curing Oven

 - User Manual

 - Wiring Diagram

DIMENSIONS:

 - External: 24” x 24” x 48”

 - Internal: 16.5” x 16.5” x 44”

DESCRIPTION:

 - Double walled with galvanized steel sheeting both inside and out



 - Heavy duty galvanized steel flooring, heavy enough to protect the flooring underneath, thin enough to roll carts in and out of the oven



 - One (1) long-life mineral insulated metal sheathed heating elements

 - The chamber door opens out providing access to the full width of the chamber

- Chamber walls and door encased with mineral fiber insulation (rated @ 2100F), providing maximum thermal efficiency



 - High temperature silicone compound gasket provides a seal within the chamber

 - Ceramic fiberglass door gasket



 - Commercial Grade ball bearing oven door hinges

 - Industrial Strength door latch clamps



 - Made in USA

CONTROL SYSTEM:

 - Side Mounted Control Panel

 - Digital temperature control, display set temperature as well as actual temperature inside the heating chamber



 - Thermocouple
- On/Off Breaker Switch
